1771-OFE2K/B
- Isolated Analog Output Card
- Outputs per Module: 4 individually isolated
- Output Current range: +4 to +20 mA
- Resolution: 12-bit Binary
- Accuracy: +0.1% of full scale
- Max Loop Impedance: Up to 1200Ω Load Resistance
- Backplane Current: 1.50A @ 5V dc ±5%
- Internal scan rate: 8.0ms for all Channels
- Isolation: 1000Vrms
Cards and related modules
Quality Assurance for Products
Product Authenticity Guarantee
Shipping Everywhere
Responsive support
General Information 1771-OFE2K/B
- Isolated Analog Output Card
- Outputs per Module: 4 individually isolated
- Output Current range: +4 to +20 mA
- Resolution: 12-bit Binary
- Accuracy: +0.1% of full scale
- Max Loop Impedance: Up to 1200Ω Load Resistance
- Backplane Current:50A at 5V DC ±5%
- Internal scan rate:0ms for all Channels
- Isolation: 1000Vrms
